Description
Precision Voltage Regulation with Integrated Conditioning
📞 Call Now: +254 707 122 122 | 🛒 Order Online: shopstemaengineering.com
⚙️ Technical Specifications
| Feature | Details |
|---|---|
| Power Ratings | Customizable (commonly 10 kVA – 2,000+ kVA) |
| Input Voltage Range | ±10%, ±15%, ±25%, up to ±45% (based on model) |
| Output Voltage Accuracy | ±1% |
| Technology | Electromechanical servo-controlled + integrated electronic filters |
| Phases | Three-phase (balanced/unbalanced load support) |
| Frequency | 50 / 60 Hz |
| Efficiency | >98% |
| Response Time | ~10 ms/V (typical) |
| Cooling System | Natural or forced ventilation (depending on size) |
| Enclosure Protection | IP21 (standard), IP23/IP54 available |
| Harmonic Filtering | Included as standard |
| Surge Protection | Built-in protection against spikes, transients, and surges |
| Certifications | CE, ISO 9001, RoHS |
| Country of Origin | 🇮🇹 Italy |
✅ Key Features & Benefits
⚙️ All-in-One Power Conditioning
-
Combines voltage regulation, EMI/RFI filtering, and surge suppression into a single unit for total load protection.
🧠 Microprocessor-Controlled Precision
-
Delivers consistent ±1% voltage with real-time digital monitoring and diagnostics.
🔧 Built for Demanding Environments
-
Handles non-linear loads, unbalanced phases, and frequent fluctuations — ideal for African grid conditions.
🛡️ Enhanced Safety
-
Includes electronic protections, temperature sensors, motor braking, and alarms for overload and phase failure.
🧳 Space-Saving and Customizable
-
Modular internal structure and compact footprint for simplified installation and easy servicing.
🏭 Ideal Applications
| Industry | Application |
|---|---|
| Medical & Healthcare | MRI, CT scanners, diagnostics, and surgical instruments |
| Telecom | BTS sites, switching hubs, broadcast stations |
| Industrial | CNCs, robotics, PLCs, sensitive motors |
| Data Centers | UPS input stability, server racks, switchgear |
| Laboratories | Measurement, calibration, R&D test benches |
| Aviation/Transport | Control systems, ground electronics, runway lighting |
🆚 Ortea Odyssey vs Standard Voltage Stabilizers
| Feature | Ortea Odyssey | Conventional Stabilizers |
|---|---|---|
| Input Voltage Tolerance | Up to ±45% | Typically ±15–25% |
| Output Accuracy | ±1% | ±3% to ±5% |
| Surge & Harmonic Protection | ✅ Built-in | ❌ External device required |
| Load Handling (Unbalanced) | ✅ High tolerance | ⚠️ Limited |
| Application Class | Critical equipment-grade | General-purpose only |
| Remote Monitoring | ✅ Available (optional) | ❌ Rarely included |
📦 Example Configurations
| Model | Power Rating | Input Range | Use Case |
|---|---|---|---|
| Odyssey-20 | 20 kVA | ±15% | Laboratory, test benches |
| Odyssey-100 | 100 kVA | ±25% | Medical imaging systems |
| Odyssey-500 | 500 kVA | ±35% | Industrial production lines |
| Odyssey-1200 | 1,200 kVA | ±45% | Large-scale data center infrastructure |
🧰 Optional Add-ons
-
🔌 Automatic Bypass Systems
-
🌐 SNMP/Modbus Monitoring Interfaces
-
⚡ Extended Surge Arrestor Packs
-
🧱 Outdoor/Marine-Grade Enclosures
-
📊 Touchscreen HMI for Live Monitoring
🚀 Why Buy from Shop Stema Engineering?
-
🛠️ Authorized Ortea Distributor in East Africa
-
📊 Expert Load Assessment & Configuration Support
-
🚚 Fast Delivery & On-Site Installation Services
-
🛡️ After-Sales Support, AMC & Spare Parts Available
-
📞 Call or WhatsApp Anytime: +254 707 122 122
📞 Secure Your Critical Power Today
With the Ortea Odyssey, you get world-class voltage stability, integrated filtering, and surge protection — all from one intelligently designed unit.
📞 Call Now: +254 707 122 122
📧 Email: info@stemaengineering.com
🌐 Order Online: www.shopstemaengineering.com
